Desktop Switch TP-Link LS1005G

The TP-Link LS1005G desktop switch is an unmanaged network device designed to provide reliable and efficient connectivity in home and small office environments. This model features 5 Gigabit Ethernet RJ-45 ports, allowing data transfers at speeds up to 1,000 Mbps, enabling multiple devices to connect simultaneously without performance loss. Its 10 Gbit/s switching capacity ensures fast internal communication, ideal for boosting network responsiveness and productivity. Housed in a sturdy black metal chassis, the LS1005G offers durability and efficient heat dissipation, with a compact design that supports wall mounting to optimize workspace. Its low power consumption of 1.65 W promotes efficient and eco-friendly use, making it cost-effective in terms of electricity. Compatible with IEEE 802.3i, 802.3u, and 802.3x standards, it guarantees stable operation and broad device compatibility. It operates on a 5 V DC input voltage, providing safe and simple power supply. An installation guide is included to facilitate easy setup. In summary, the TP-Link LS1005G is a simple, reliable, and efficient solution to expand local networks with a device that combines build quality and performance in a practical, versatile mounting-ready format.

• Speed:
  • 10/100/1000 Mbps
  • 1000 Mbps
• Energy consumption: 1,65 W
• Characteristics:
  • LED in operation indicator
  • Wall mounting
  • Installation guide included
• Power supply:
  • Electric Network
  • DC
• Approx. dimensions: 8,36 x 4,57 x 2,28 cm
• Product with plug: Yes
• Type of plug: Plug EU
• Colour: Black
• Material:
  • Metal
  • Plastic
• Voltage:
  • 5 V
  • 220 V
• Ports: 5
• IP rating: IP55
• Connections:
  • Ethernet LAN
  • RJ45 x 5
• Amperage:
  • 1 A
  • 0,6 A
• Certificate: CE, FCC, RoHS
• Weight: 180 g
• LED indicator: switching on, change of intensity or charge
• Working range for humidity: 10 % - 90 %
• Approx. temperature: -40º / 70º

Let LiteWave Bring You Lighter Network Life The TP-Link LiteWave Series Unmanaged Switches provide easy and affordable way to expand your wired network. They are easy to use and reliable. With these plug-and-play switches, you can expand your network connections to multiple devices instantly. With all ports support Auto-MDI/MDIX, there’s no need to worry about the type of cable to use. Go Green with Your Ethernet The LiteWave Series also supports energy-efficient technology, helping you save power and money. Power consumption automatically adjusts according to link status and cable length, allowing you to expand your network while minimizing your carbon footprint. Save the planet and lower your energy bills — it’s a win-win! Gigabit Ports For Faster Speeds Increase the speed of your network with the LS1005G 5-port Gigabit desktop switch. Non-blocking, 5× 10/100/1000Mbps ports enable instant transferring of large, bandwidth intensive files without interference. Use Where You Need, However You Need The LS1005G is fully compatible with networked devices such as computers, printers, webcams, IPTVs. It has a wide range of application scenarios and is suitable for networking in school dormitories, surveillance, homes, and small businesses.

• Switch type: Unmanaged
• Basic switching RJ-45 Ethernet ports quantity: 8
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• Networking standards: IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
• 10G support: N
• Flow control support: Y
• Auto MDI/MDI-X: Y
• Auto-negotiation: Y
• MAC address table: 2000 entries
• Switching capacity: 10 Gbit/s
• Forwarding rate: 7.4 Mpps
• Store-and-forward: Y
• Jumbo frames support: Y
• Jumbo frames: 16000
• Packet buffer memory: 1.5 MB
• Rack mounting: N
• Product colour: Black
• Housing material: Plastic
• LED indicators: Y
• International Protection (IP) code: IP20, IP40
• Wall mountable: Y
• Certification: CE, FCC, RoHS
• Power supply included: Y
• DC input voltage: 5 V
• Input current: 0.6 A
• Power consumption (max): 3.7 W
• Power over Ethernet (PoE): N
• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 10 - 90%
• Storage relative humidity (H-H): 5 - 90%
• Heat dissipation: 12.617 BTU/h
• Width: 90 mm
• Depth: 72 mm
• Height: 24 mm
• Quick start guide: Y
• Package type: Box
• Package width: 94 mm
• Package depth: 91 mm
• Package height: 84 mm
