NAS Network Storage Synology RS1619XS+ Quad Core Black

• Hard Drive:
  • 128 GB SSD
  • 8 GB
• Type of plug: Plug EU
• Product with plug: Yes
• Type:
  • Server
  • DDR4
  • HDD/SSD
  • NAS
• Power supply:
  • Cable
  • CA cable
  • Inside
• Compatible:
  • HDD/SSD
  • 2,5"-3,5"
  • MAC OS X 10.13 HIGH SIERRA
  • Windows 7
  • Windows 10
  • MAC OS X 10.12 SIERRA
  • MAC OS X 10.14 MOJAVE
  • MAC OS X 10.11 EL CAPITAN
  • Windows Server 2016
  • Intel® Turbo Boost Technology 2.0
  • Raid 0,1,5,6,10,JBOD
• Voltage:
  • 100-240 V
  • 100 - 240 V
• Frequency:
  • 50-60 Hz
  • 50 - 60 Hz
  • 2,7 GHz
• Width:
  • 480 mm
  • 48 cm
• Number of Running Threads: 8
• Speed:
  • 10 Gbit/s
  • 1000 Mbit/s
  • 2,7 GHz
  • 2,2 ghz
  • 10/100/1000 Mbps
  • 2.2 GHz
• Interface:
  • Sata III
  • Sata II
• Size: 2,5"
• Connections:
  • 2
  • USB x 2
  • USB
  • SATA
  • Ethernet LAN
  • USB-A 3.2
• AC input voltage: 100-240 V
• Cache:
  • L3
  • 6 MB
• Internal Memory: 8 GB
• Height: 4,4 cm
• Characteristics:
  • Silent mode
  • On/off interrupter
  • LED indicator
  • Installation guide included
  • Idle states
• Processor:
  • Quad Core
  • Intel Xeon D-1527
• RAM Memory: 8 GB RAM
• Colour: Black
• Power: 35 W
• Ventilator: 2
• 3.5" bays: 4
• Rechargeable lithium battery: 150 mAh
• Certificate: RoHS
• Requirements: 64 bits
• Not included: WiFi
• Memory Type: DDR4
• Operating System: DiskStation Manager
• Technology:
  • VT-d
  • VT-x
  • Execute Disable Bit (XD Bit)
• Nuclei: 4 Nuclei
• Processor Family: Intel

Synology RackStation RS1619xs+ is a high-performance 1U rackmount NAS with comprehensive storage, data backup, and collaboration applications, suitable for small- to medium-sized businesses. RS1619xs+ simplifies data management, optimizes virtualization environments, and rapidly expands storage capacity with minimal time investment in setup and maintenance. Synology RS1619xs+ is backed by Synology’s 5-year limited warranty. Synology RS1619xs+ is a 1U 4-bay rackmount network attached storage solution equipped with a quad-core processor, 8 GB DDR4 memory (expandable up to 64 GB), and four Gigabit LAN ports. With an optional 10GbE network adapter card installed, RS1619xs+ delivers sequential reading throughput over 1,523 MB/s and 162,097 iSCSI random read IOPS under a RAID 5 configuration. RS1619xs+ comes with two onboard M.2 SSD slots, allowing fast system cache creation with M.2 2280 NVMe/SATA SSDs without occupying internal 3.5" drive bays. RS1619xs+ also provides great flexibility to easily scale up to 16 drives when connected to one Synology RX1217/RX1217RP expansion unit. Storage capacity can be expanded according to your business needs with minimal effort.

• Storage drives installed: N
• Number of storage drives supported: 4
• Installed storage drive type: N
• Supported storage drive types: HDD & SSD
• Storage drive interface: Serial ATA, Serial ATA II, Serial ATA III
• RAID support: Y
• Storage drive sizes supported: 2.5,3.5"
• Number of M.2 (M & B) slots: 2
• RAID levels: 0,1,5,6,10,JBOD
• Hot-swap drive bays: Y
• Supported file systems: BTRFS,FAT,HFS+,NTFS,ext3,ext4
• Processor family: Intel® Xeon® D
• Processor manufacturer: Intel
• Processor model: D-1527
• Processor frequency: 2.2 GHz
• Processor boost frequency: 2.7 GHz
• Processor cores: 4
• Processor threads: 8
• Processor cache: 6 MB
• CPU configuration (max): 1
• ECC supported by processor: Y
• PCI Express configurations: 1x16,1x4,1x8
• PCI Express slots version: 2.0,3.0
• Processor cache type: L3
• Processor code: SR2DK
• Processor codename: Broadwell
• Processor lithography: 14 nm
• Processor operating modes: 64-bit
• Processor package size: 37.5 x 37.5 mm
• Processor series: Intel Xeon D-1500
• Processor socket: BGA 1667
• Scalability: 1S
• Stepping: V2
• Thermal Design Power (TDP): 35 W
• Maximum internal memory supported by processor: 128 GB
• Conflict-Free processor: Y
• Internal memory: 8 GB
• Internal memory type: DDR4
• Maximum RAM supported: 64 GB
• Memory slots: 4
• Ethernet LAN: Y
• Ethernet LAN data rates: 10,100,1000 Mbit/s
• Wi-Fi: N
• iSCSI support: Y
• Wake-on-LAN ready: Y
• Supported network protocols: CIFS,AFP,NFS,FTP,WebDAV,CalDAV,iSCSI,Telnet,SSH,SNMP,VPN (PPTP, OpenVPN, L2TP)
• Link aggregation: Y
• USB port: Y
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
• PCI Express x8 (Gen 3.x) slots: 1
• Expansion ports quantity: 1
• Chassis type: Rack (1U)
• Cooling type: Active
• Product colour: Black
• Number of fans: 2 fan(s)
• Fan diameter: 4 cm
• LED indicators: Alarm, HDD, Power, Status
• Type: NAS
• Device class: Small & Medium Business
• Backup function: Y
• Backup features: Cloud, iSCSI LUN
• Multilingual support: Y
• Noise level: 39.3 dB
• Web-based management: Y
• Security algorithms: HTTPS,SSH,SSL/TLS
• Access Control List (ACL): Y
• Reset button: Y
• On/off switch: Y
• Browser supported: Chrome, Firefox, Internet Explorer 10+, Safari 10+
• Operating system installed: DiskStation Manager
• Windows operating systems supported: Windows 10,Windows 7
• Mac operating systems supported: Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
• Server operating systems supported: Windows Server 2016
• Power supply location: Built-in
• Power supply unit (PSU) capacity: 150 W
• Number of power supply units: 2
• Power consumption (typical): 68.68 W
• Power consumption (HDD standby): 34.78 W
• AC input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• Width: 480 mm
• Depth: 518.6 mm
• Height: 44 mm
• Weight: 8.16 kg
• Cables included: AC
• Quick installation guide: Y
• Sustainability certificates: RoHS
• Embedded options available: Y
• Enhanced Intel SpeedStep Technology: Y
• Execute Disable Bit: Y
• Idle States: Y
• Intel 64: Y
• Intel Enhanced Halt State: Y
• Intel Secure Key Technology version: 1.00
• Intel Trusted Execution Technology: Y
• Intel TSX-NI: Y
• Intel TSX-NI version: 1.00
• Intel Virtualization Technology (VT-x): Y
• Intel Virtualization Technology for Directed I/O (VT-d): Y
• Intel VT-x with Extended Page Tables (EPT): Y
• Intel® AES New Instructions (Intel® AES-NI): Y
• Intel® Hyper Threading Technology (Intel® HT Technology): Y
• Intel® OS Guard: Y
• Intel® Secure Key: Y
• Intel® Turbo Boost Technology: 2.0
• Maximum number of PCI Express lanes: 32
• Thermal Monitoring Technologies: Y
• UART: Y
• Memory channels supported by processor: Dual
• Memory types supported by processor: DDR3-SDRAM,DDR4-SDRAM
• Operating temperature (T-T): 5 - 35 °C
• Operating relative humidity (H-H): 5 - 95%
• Storage temperature (T-T): -20 - 60 °C
• Operating altitude: 0 - 5000 m
• Certification: EAC VCCI RCM FCC CE BSMI
• Processor ARK ID: 91195
