Switch TP-Link TL-SG2210P

The TL-SG2210P from TP-Link is a managed switch that combines high capacity and versatility for professional network environments. Designed for advanced management features, it operates at L2 and L4 layers, enabling comprehensive control of data traffic and service prioritization in enterprise or mid-sized networks. It includes 8 Gigabit Ethernet RJ-45 ports ensuring fast and stable connections, plus a built-in PoE+ port that powers compatible devices like IP cameras or VoIP phones without external power supplies, simplifying infrastructure. It also features two SFP ports that expand connectivity options via fiber optic links, ideal for long-distance transmissions or high-speed connections. Its switching capacity reaches 20 Gbit/s, supporting up to 8,000 MAC table entries, ensuring smooth handling of large data volumes and efficient network segmentation. The chassis is made of black plastic with LED indicators that facilitate monitoring of port status and activity. It complies with various IEEE network standards, including IEEE 802.1D for spanning tree, 802.1Q for VLANs, and 802.3 for Ethernet, as well as advanced security protocols like 802.1X, ensuring secure and professional deployment. The TL-SG2210P stands out for its partial cross-platform compatibility and English support, aimed at network administrators who require a robust, efficient, and flexible device for advanced infrastructure management. Overall, this switch offers a solid balance of performance, PoE capability, and comprehensive management, making it a reliable solution for environments demanding gigabit connectivity with professional features.

• Colour: Black
• Frequency: 50-60 Hz
• Voltage:
  • 100-240 V
  • 220 V
• Connections:
  • PoE x 1
  • RJ45
  • Ethernet LAN
  • rj45 x 8
• Feeding dish included: Yes
• Product with plug: Yes
• Type of plug: Plug EU
• Ports:
  • 8
  • 10
• Type: Switch
• AC input voltage: 100-240 V
• Material: Plastic
• Characteristics:
  • LED indicator
  • LED in operation indicator
• Platform: Windows
• Holder: Multi-support
• Language: English
• Power supply:
  • CA cable
  • Iincluded
• Certificate: CE, FCC, RoHS
• AC input frequency: 50-60 Hz
• Weight: 620 g
• Working range for humidity: 10 % - 90 %
• Compatible: PC
• Approx. temperature: -40º / 70º
• Includes: User manual
• Safety: IGMP
• Nuclei: 1 core

What This Product Does TP-LINK Gigabit Smart Switch TL-SG2210P is equipped with 8 gigabit RJ45 ports and 2 SFP slots, all RJ45 Ports support the PoE standard with total PoE power budget of 53W and useful PoE power management features. The switch provides high performance, enterprise-level QoS, useful security strategies and rich layer 2 management features. TP-LINK’s Gigabit Smart Switch TL-SG2210P is especially designed for the small and medium business networks that require efficient network management. TL-SG2210P comes with a comprehensive set of features, such as Link Aggregation Group, 802.1Q VLAN, Access Control Lists (ACL), Quality of Service(QoS L2 to L4), Storm Control and IGMP Snooping to provide a small or medium-sized business with a network that is geared for growth while ensuring performance and reliability. What’s more, its easy-to-use web management interface means faster setup and configuration with less downtime, providing the ideal solution for your business network. IEEE 802.3af-compliant Power over Ethernet The TL-SG2210P supports 8 ports of IEEE 802.3af-compliant PoE and has a total power supply of 53W to power any 802.3af compliant power device. It’s an efficient and cost-effective choice to work with wireless access points, surveillance cameras, IP phones and other PoE supported devices, while getting rid of cables or power lines running around. Compact and flexible, the TL-SG2210P is ideal to flexibly use PoE to deploy wireless access points or IP-based network surveillance cameras for projects or small business networks. Advanced QoS Features To integrate voice, data and video service on one network, the switch applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including Port Priority, 802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and jitter free.In conjunction with the Voice VLAN the switch supports, the voice applications will operate with much smoother performance. Abundant Layer 2 Features For more application of layer 2 switches, TL-SG2210P supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol and 802.3x Flow Control function. Any more, the switches provide advanced features for network maintenance such as Loop Back Detection, Cable Diagnostics and IGMP Snooping. IGMP Snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling & filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Enterprise Level Management Features TL-SG2210P is easy to use and manage. It supports various user-friendly standard management features, such as intuitive web-based Graphical User Interface(GUI) or industry-standard Command Line Interface(CLI). SNMP (v1/2/3) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events.

• Switch type: Managed
• Switch layer: L2
• Quality of Service (QoS) support: Y
• Web-based management: Y
• MIB support: Y
• Basic switching RJ-45 Ethernet ports quantity: 8
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• SFP module slots quantity: 2
• Fiber ports quantity: 2
• Fiber optic connector: SFP
• Console port: RJ-45
• Networking standards: IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
• 10G support: N
• Copper ethernet cabling technology: 1000BASE-T,1000BASE-TX,10BASE-T
• Port mirroring: Y
• Flow control support: Y
• Broadcast storm control: Y
• Rate limiting: Y
• Auto MDI/MDI-X: Y
• Spanning tree protocol: Y
• VLAN support: Y
• Number of VLANs: 512
• Fiber ethernet cabling technology: 1000BASE-X,100BASE-FX
• Fiber type: Multi-mode
• MAC address table: 8000 entries
• Switching capacity: 20 Gbit/s
• Forwarding rate: 14.88 Mpps
• Store-and-forward: Y
• Number of queues: 4
• Jumbo frames support: Y
• Jumbo frames: 9216
• Packet buffer memory: 0.512 MB
• Access Control List (ACL): Y
• IGMP snooping: Y
• Security algorithms: SNMP,SSH,SSH-2
• MAC address filtering: Y
• SSH/SSL support: Y
• Multicast support: Y
• Product colour: Black
• LED indicators: Link, PoE, Power
• Certification: CE, FCC, RoHS
• Compatible operating systems: Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.
• Fanless: Y
• Minimum system requirements: Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.
• AC input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• DC input voltage: 53 V
• Input current: 1.31 A
• Power over Ethernet (PoE): Y
• Power over Ethernet (PoE) ports quantity: 8
• Total Power over Ethernet (PoE) budget: 53 W
• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 10 - 90%
• Storage relative humidity (H-H): 5 - 90%
• Width: 209 mm
• Depth: 126 mm
• Height: 26 mm
• Cables included: AC
• Quick start guide: Y
• Package width: 315 mm
• Package depth: 240 mm
• Package height: 70 mm
