Switch D-Link DGS-1100-05V2/E 5xGbE

The DGS-1100-05V2 switch from D-Link is a network device designed for office and home environments, offering 5 Gigabit Ethernet RJ45 ports for fast and stable LAN connections, suitable for linking computers, printers, and other network devices. With a total switching capacity of 10 Gbps and a maximum packet forwarding rate of 7.44 Mpps, it manages data traffic smoothly, optimizing local network performance. It features a MAC address table with 2,000 entries and a 1 Mbit packet buffer, enabling efficient traffic handling without data loss. Its compact desktop design, measuring 100.5 x 82 x 28 mm and weighing only 0.23 kg, is made of black metal, providing durability and proper heat dissipation. The device has low power consumption, up to 3.42 W, and complies with IEEE 802.3az energy efficiency standards, helping save energy through link and cable length management. For network management, the switch supports advanced port-based VLAN configurations, including voice, management, and surveillance VLANs, with support for up to 32 static VLAN groups and a maximum of 4,094 VLAN IDs (VIDs), offering flexibility to segment traffic and enhance security. It also includes layer 2 features such as IEEE 802.3x flow control, HOL blocking prevention, Jumbo Frame support up to 9,216 bytes, and IGMP snooping with support for 32 groups to optimize multicast handling. Security features include static MAC address control (up to 32 entries) and mechanisms to prevent broadcast, multicast, and unknown unicast storms. Management is easy via a web GUI (IPv4 support) and the SmartConsole client utility, facilitating configuration and monitoring even for users with basic knowledge. It holds international safety and EMI/EMC certifications such as FCC Class B, CE Class B, and others, ensuring reliable operation. Power is supplied by an external adapter with an input of 240 VAC at 50-60 Hz. All these features make the DGS-1100-05V2 a reliable and efficient solution for environments requiring a switch with advanced basic management, good performance, and low power consumption in a compact, sturdy format.

• Power supply: Electric Network
• AC input voltage: 100-240V
• Approx. weight: 230 g
• Approx. dimensions: 10 x 8,2 x 2,8 cm
• Connections:
  • Ethernet LAN
  • RJ45 x 5
• Product with plug: Yes
• Type of plug: Plug EU
• Type:
  • Switch
  • Tablecloth
• Speed: 1 Gbps
• Colour: Black
• Material:
  • Metal
  • Aluminium
  • Plastic
• Voltage:
  • 5 V
  • 100 - 240 V
• Ports: 5
• Amperage: 1 A
• Accuracy (relative humidity): 0 % - 90 %
• Approx. temperature: -40º / 70º

Advanced Security Features The DGS-1100 series’ web user interface gives administrators an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), and link aggregation (desktop models utilize Static Trunk). With powerful security features including IGMP snooping, Static MAC, and Storm Control, these smart managed switches are a versatile solution for deployments that require easy to configure functionality without added complexities. Simplify Network Management D-Link’s free Network Assistant (DNA) utility displays all your connected devices and makes first-time configuration a breeze. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools. Easy Troubleshooting The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily. Loopback Detection detects loops created by a specific port and automatically shuts down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors. Green Technology D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. The desktop models in the series utilize a fanless design, for silent and energy-efficient operation. All models are also IEEE 802.3az-compliant and feature Link Status detection.

• Switch type: Managed
• Basic switching RJ-45 Ethernet ports quantity: 5
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• Copper ethernet cabling technology: 1000BASE-T
• Auto MDI/MDI-X: Y
• Switching capacity: 10 Gbit/s
• Forwarding rate: 7.4 Mpps
• Packet buffer memory: 0.125 MB
• Product colour: Black
• Reset button: Y
• Fanless: Y
• AC input voltage: 100 - 240 V
• DC input voltage: 5 V
• Input current: 1 A
• Power consumption (max): 3.42 W
• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 0 - 90%
• Storage relative humidity (H-H): 0 - 95%
• Operating altitude: 0 - 2000 m
• Width: 100.5 mm
• Depth: 28 mm
• Height: 82 mm
• Weight: 230 g
